Description

The SPLC-XL5E-16T industrial controllers are the main processor module of the modular controllers with Ethernet in the XL5E series by Xinje. They offer full functionality of standard XL3, but are technically superior — featuring more memory, high computation speed and expansion to a larger number of I/O points (up to 528), as well as supporting high-speed communication via Ethernet bus. Features of the industrial PLC series:

programming using the free development environment XDPPro with ladder diagrams, instruction list, C;
have built-in 8 digital inputs and 8 digital outputs (transistor), allow connecting the required number of analog, digital, and special inputs-outputs through expansion modules (1 ED module on the left and another 16 expansion modules on the right);
special functions — pulse output, high-speed counter, pulse-width modulation, frequency measurement, control of two axes, etc.;
have USB port and communication ports supporting Modbus, RS232/485, Ethernet protocols up to 100 Mbps;
storage in Xinje Cloud service allows for remote programming and monitoring of controllers via the internet.

Technical specifications table of processor module SPLC-XL5-16T
Number of built-in input points		8
Number of built-in output points		8
Max. number of I/O points		528
High-speed input		3 channels A/B 200K
High-speed output		pulse output 2 axis (2 PUL/DIR)
Number of expansion modules	left	up to 1 "ED" expansion module
Number of expansion modules	right	up to 16 expansion modules
Interrupts	external	6
	timer	20
	other	high-speed counter interruption, pulse interruption
Communication	Ports	1 port RS232, 1 port RS485, 2 ports RJ45
Communication	Protocol	Standard Modbus ASCII/RTU connection
Bus function		Field bus X-NET
PWM		PWM supported
Frequency measurement		Frequency measurement supported
Precise timing		26 points ET0~ET52 (only even numbers)
Multiple station control		Supported
Backup on power-off		On power-off, data is held in FlashROM, 3V lithium coin battery
Processing speed of main function		0.01~0.03us
User program capacity		1 MB
Power supply voltage		24V
