Inductive proximity sensor NPN, M30, distance up to 15 mm (TKI/TKL series)

Do you have any questions about the product?
We will be happy to answer them in messengers

Inductive proximity sensor NPN, M30, distance up to 15 mm (TKI/TKL series)

Name: Inductive proximity sensor NPN, M30, distance up to 15 mm (TKI/TKL series)
Brand: Specialist
SKU: SPLC-TKI-30N15C
Price: 831.90 UAH
Availability: BackOrder

On order

Type of transistor output

NPN NC NPN NO

Роз'єм

Кутовий Прямий

Model

Manufacturer

Specialist

1 279,23 UAH

-34%

from 831,90 UAH

Qty:

Do you have any questions about the product?
We will be happy to answer them in messengers

Delivery of goods

More details

New Post Office and address

≈ 250 UAH / Free for orders over 5,000 UAH

2-4 days

By courier in Ukraine

≈ 350 UAH / Free for orders over 5,000 UAH

1-2 days

Pickup from our warehouse

Free

Today, after 2:00 PM

Payment

More details

Models

Found 4 variants


Name

Model Price Availability Qty

Action

SPLC-TKI-30N15C

Inductive proximity sensor NPN, M30, distance up to 15 mm (TKI/TKL series)

Type of transistor output=NPN NO Роз'єм=Прямий

SPLC-TKI-30N15C

1 279,23 UAH 831,90 UAH

Pre-Order

SPLC-TKL-30N15C

Inductive proximity sensor NPN, M30, distance up to 15 mm (TKI/TKL series)

Type of transistor output=NPN NO Роз'єм=Кутовий

SPLC-TKL-30N15C

1 279,22 UAH 831,90 UAH

Pre-Order

SPLC-TKI-30NC15C

Inductive proximity sensor NPN, M30, distance up to 15 mm (TKI/TKL series)

Type of transistor output=NPN NC Роз'єм=Прямий

SPLC-TKI-30NC15C

1 279,23 UAH 831,90 UAH

Pre-Order

SPLC-TKL-30NC15C

Inductive proximity sensor NPN, M30, distance up to 15 mm (TKI/TKL series)

Type of transistor output=NPN NC Роз'єм=Кутовий

SPLC-TKL-30NC15C

1 279,22 UAH 831,90 UAH

Pre-Order

Technical specifications

Transistor output type

NPN NC, NPN NO

Роз'єм

Кутовий, Прямий

Delivery time

60 днів

Description

Contactless inductive sensor 24V DC NPN-type SE-SEN-TKI(L)-30N(C)15C is used for proximity detection, position control, counting, and speed determination of metal target objects. The detection distance of the limit switch on metals is up to 15 mm. This sensor model features a transistor and electronic components that withstand external load up to 200 mA, high resistance to electromagnetic interference due to optimally selected frequency 100 Hz, moisture-resistant casing IP66, visible 360-degree light indication, round pin-3 or pin-4 connector for wire connection — quality shielded three-wire signal cable length 2 m included.

Technical specifications table of magnetic-inductive proximity sensor SE-SEN-TKI(L)-30N(C)15C
Output type	3-wire NPN NO or NPN NC
Detector	Detection of metals (steel, stainless steel, chrome, nickel, copper, aluminum, etc.)
Standard detection object	Iron plate 30×30×1 mm
Detection distance	Sn = 15 mm
Effective working distance	from 0 to 12 mm
Frequency	≤100 Hz
Power supply	DC 10…30 Volts
Max load	≤200 mA
Housing	Screw-in cylindrical with M30 thread
Connection	Cable length 2 metres
IEC protection class	IP66

Connection diagram of VBI sensor NPN type
