Digital expansion module SPLC-XL-E8X8YT for 8 inputs and 8 outputs transistor for Xinje XL series controllers

Do you have any questions about the product?
We will be happy to answer them in messengers

Digital expansion module SPLC-XL-E8X8YT for 8 inputs and 8 outputs transistor for Xinje XL series controllers

Name: Digital expansion module SPLC-XL-E8X8YT for 8 inputs and 8 outputs transistor for Xinje XL series controllers
Brand: Xinje
SKU: SPLC-XL-E8X8YT
Price: 2332.44 UAH
Availability: InStock

In Stock

Product Code:

SPLC-XL-E8X8YT

Brand:

Xinje

2 332,44 UAH

Qty:

Do you have any questions about the product?
We will be happy to answer them in messengers

Delivery of goods

More details

New Post Office and address

≈ 250 UAH / Free for orders over 5,000 UAH

2-4 days

By courier in Ukraine

≈ 350 UAH / Free for orders over 5,000 UAH

1-2 days

Pickup from our warehouse

Free

Today, after 2:00 PM

Payment

More details

Description

The SPLC-XL-E8X8YT digital expansion modules are designed for the ultra-thin industrial controllers of the Xinje XL series and connect to the right of the main processor module. The expansion module allows increasing the number of inputs and outputs for PLC XL3, XL5 and XL5E. Features of the module:

easily connect to controllers via the side interface connector, providing data and power transmission;
support digital NPN input type, transistor outputs;
if the number of expansion modules is equal to or more than 5, a terminal resistor XL-ETR must be installed at the end of the controller blocks;

Technical Specifications Table for Module SPLC-XL-E8X8YT
Number of Inputs	8 input points
Polling Time	up to 20 ms
Input Type	NPN
Rated Input Voltage	24 V DC
Number of Outputs	8 output points
Output Polling Time	up to 0.2 ms
Max. Output Load	resistive — 3 A, inductive — 12 W 80 V⋅A
External Connection	Terminals for external wiring
