Inductive proximity sensor PNP, M18, distance up to 5 mm (TKI/TKL series)

Do you have any questions about the product?
We will be happy to answer them in messengers

Inductive proximity sensor PNP, M18, distance up to 5 mm (TKI/TKL series)

Name: Inductive proximity sensor PNP, M18, distance up to 5 mm (TKI/TKL series)
Brand: Specialist
SKU: SPLC-TKI-18P5C
Price: 755.82 UAH
Availability: InStock

Out Of Stock

Type of transistor output

PNP NC PNP NO

Роз'єм

Кутовий Прямий

Model

Manufacturer

Specialist

1 163,35 UAH

-35%

from 755,82 UAH

Сповістити про наявність

Do you have any questions about the product?
We will be happy to answer them in messengers

Delivery of goods

More details

New Post Office and address

≈ 250 UAH / Free for orders over 5,000 UAH

2-4 days

By courier in Ukraine

≈ 350 UAH / Free for orders over 5,000 UAH

1-2 days

Pickup from our warehouse

Free

Today, after 2:00 PM

Payment

More details

Models

Found 4 variants


Name

Model Price Availability Qty

Action

SPLC-TKI-18P5C

Inductive proximity sensor PNP, M18, distance up to 5 mm (TKI/TKL series)

Type of transistor output=PNP NO Роз'єм=Прямий

SPLC-TKI-18P5C

1 163,35 UAH 755,82 UAH

In Stock

SPLC-TKL-18P5C

Inductive proximity sensor PNP, M18, distance up to 5 mm (TKI/TKL series)

Type of transistor output=PNP NO Роз'єм=Кутовий

SPLC-TKL-18P5C

1 163,35 UAH 755,82 UAH

In Stock

SPLC-TKI-18PC5C

Inductive proximity sensor PNP, M18, distance up to 5 mm (TKI/TKL series)

Type of transistor output=PNP NC Роз'єм=Прямий

SPLC-TKI-18PC5C

1 163,35 UAH 755,82 UAH

In Stock

SPLC-TKL-18PC5C

Inductive proximity sensor PNP, M18, distance up to 5 mm (TKI/TKL series)

Type of transistor output=PNP NC Роз'єм=Кутовий

SPLC-TKL-18PC5C

1 163,35 UAH 755,82 UAH

In Stock

Technical specifications

Transistor output type

PNP NC, PNP NO

Роз'єм

Кутовий, Прямий

Delivery time

60 днів

Description

Contactless inductive sensor 24V DC PNP-type SE-SEN-TKІ(L)-18P(C)5C is used for proximity detection, position control, counting, speed determination of metallic target objects. The trigger distance on metals — up to 5 mm. This sensor model has transistor and electronic components capable of handling external load up to 200 mA, high resistance to electromagnetic interference thanks to optimally selected frequency 400 Hz, moisture-resistant case IP66, visible 360-degree light indication, round pin-3 or pin-4 connector for wire connection — quality PVC three-wire signal cable length 2 m included.

Technical Specifications Table of Magnetic Inductive Proximity Sensor SE-SEN-TKІ(L)-18P(C)5C
Output Type	3-wire PNP NO or PNP NC
Detector	Metal detection (steel, stainless steel, chrome, nickel, copper, aluminum, etc.)
Standard Detection Object	Iron plate 18×18×1 mm
Detection Range	Sn = 5 mm
Effective Operating Distance	from 0 to 4 mm
Frequency	≤400 Hz
Power Supply	DC 10…30 Volt
Max Load	≤200 mA
Body	Threaded M18 cylindrical
Connection	2-metre long cable
IEC Protection Rating	IP66

Connection Diagram of PNP Switch Sensor
