Motor (output) choke 15A, 380V, 5.5 kW, 0.94 mH (OCL-0015-0M47-0.4SC)
In Stock
Product Code:
SPLC-OCL-0015-0M47-0.4SC
Brand:
Specialist
5 481,00 UAH
Qty:
Do you have any questions about the product?
We will be happy to answer them in messengers
Delivery of goods
More details
New Post Office and address
≈ 250 UAH / Free for orders over 5,000 UAH
2-4 days
By courier in Ukraine
≈ 350 UAH / Free for orders over 5,000 UAH
1-2 days
Pickup from our warehouse
Free
Today, after 2:00 PM
Payment
More details
Technical specifications
Description
Three-phase motor choke 15A, 380V, 5.5 kW, 0.94 mH OCL-0015-0M47-0.4SC is installed at the output of a frequency converter to filter the current supplied to three-phase electric motors 380 V. The purpose of the output choke coil is as follows:
- Creating inductive resistance that limits the motor supply current, thus preventing overload and damage;
- Preventing sharp current spikes during motor startup that may fail equipment;
- Cleaning the current sine wave from unwanted high harmonics (high-frequency noises) that occur in the drive.
Use the AC output choke in the circuit between the converter and the asynchronous electric motor to improve the quality of power supply to the drive and ensure safe and long-term operation of the equipment.
Technical Specifications of Motor Output Choke OCL-0015-0M47-0.4SC
| Operating Voltage | 3 Phases 380 V |
|---|---|
| Voltage Drop | 1% for 380 V (less than 4%) |
| Operating Frequency | 50/60 Hz |
| Operating Current | 15 A |
| Maximum Current | may exceed operating by no more than 150% for 60 s |
| Inductance | 0.94 mH |
| Insulation Class | F, H |
| Protection Class | IP00 - IP22 |
| Noise | ≤65 dB |
| Temperature Rise | ≤85 K |
| Dielectric Strength | AC 3000 V/50 Hz/5 mA/10 s |
| Insulation Resistance | 100 VDC, ≤100 MΩ |
| Ambient Operating Temperature | -25 ~ +45℃ |
Operating Conditions of Motor Choke (Line Reactor) OCL-0015-0M47-0.4SC
- In the temperature range of minus 10 to 45℃ the choke’s nominal parameters are tabular. Above 55℃, the nominal current decreases by about 2% with each additional +1℃.
- Altitude above sea level should not exceed 2000 m.
- Air humidity is less than 90%.
- Environment: without harmful gases, flammable objects, with good ventilation.
When placing the choke in a cabinet, ensure ventilation for sufficient equipment cooling.
