SPLC-XL-2AD2PT-A-ED Series Combined Analog Expansion Unit for Xinje XL Series Controllers
In Stock
Product Code:
SPLC-XL-2AD2PT-A-ED
Brand:
Xinje
3 009,60 UAH
Qty:
Do you have any questions about the product?
We will be happy to answer them in messengers
Delivery of goods
More details
New Post Office and address
≈ 250 UAH / Free for orders over 5,000 UAH
2-4 days
By courier in Ukraine
≈ 350 UAH / Free for orders over 5,000 UAH
1-2 days
Pickup from our warehouse
Free
Today, after 2:00 PM
Payment
More details
Technical specifications
Description
The ultrathin combined analogue extension module series ED model SPLC-XL-2AD2PT-A-ED features analogue-digital conversion and is designed to increase the number of input points of a modular controller to 4 channels of different types. Its features include:
- a single module of this type can connect to the left of the main processor module of Xinje series XL3, XL5 or XL5E via a convenient cable-free interface (plug to plug) that transmits data and power;
- the module supports various types of input analogue signals — 2 channels for general purpose current signals, as well as 2 specialised channels for temperature sensors (Pt100 thermoresistors)
- the ED type module is very compact, saving space for installation in cabinets or panels.
| Number of Inputs | 4 inputs (total) | |
|---|---|---|
| Current | Number of Channels | 2 current inputs |
| Signal Type | 0…20 mA or 4…20 mA | |
| Conversion Accuracy | ±1% | |
| Filter Coefficient | 0~254 | |
| PT100 | Number of Channels | 2 PT100 inputs |
| Measurement Range | from −100 to 500º C | |
| Digital Output Range | from −1000 to 5000 | |
| Resolution | 0.1º C | |
| Full Accuracy | ±0.8% of full scale | |
| Conversion Speed (all channels) | 10 ms | |
| Module Power Supply | 24 V±10% DC 150 mA | |
