Scalar frequency converter 0.75 kW, 1F-3F 220V (SPLC-ESD-0R7G1)

Do you have any questions about the product?
We will be happy to answer them in messengers

Scalar frequency converter 0.75 kW, 1F-3F 220V (SPLC-ESD-0R7G1)

Name: Scalar frequency converter 0.75 kW, 1F-3F 220V (SPLC-ESD-0R7G1)
Brand: Specialist
SKU: SPLC-ESD-0R7G1
Price: 1759.00 UAH
Availability: BackOrder

In Stock

Product Code:

SPLC-ESD-0R7G1

Brand:

Specialist

2 513,00 UAH

-30%

1 759,00 UAH

Qty:

Do you have any questions about the product?
We will be happy to answer them in messengers

Delivery of goods

More details

New Post Office and address

≈ 250 UAH / Free for orders over 5,000 UAH

2-4 days

By courier in Ukraine

≈ 350 UAH / Free for orders over 5,000 UAH

1-2 days

Pickup from our warehouse

Free

Today, after 2:00 PM

Payment

More details

Technical specifications

Operating mode

Scalar control

Output frequency

0.0 to 300 Hz

Output voltage

3ph 220V

Supply voltage

3ph 220V

Power

0.75 kW

Description

Inexpensive scalar frequency inverter 0.75 kW of the NIETZ SPLC-ESD series is designed to control fans, pumps, belt conveyors and other control objects using three-phase asynchronous motors 220V up to 750W. The frequency inverter SPLC-ESD-0R7G1 connects to a single-phase 220V network.

Unlike the similar NIETZ SPLC-ESD series, this scalar control frequency inverter is cheaper to buy because it:

does not have an RS-485 interface,
has a smaller output frequency range,
has a higher nominal input-output current value.

This model is used for motor control manually via a potentiometer knob, setpoint input from the keyboard, remote analog or digital signals, for PID speed regulation using analog feedback 0…5 V, through setting 7 speeds (multi-speed mode).

Table. Main technical parameters of the frequency inverter SPLC-ESD-0R7G1
Input voltage	1ph 220 V
Output voltage	3ph 220 V
Output power	up to 0.75 kW
Output frequency range	from 0.1 to 99.0 Hz
Nominal input current	6 A
Nominal output current	3.1 A
Protection degree EN 60529	IP20

Advantages of the low-power frequency inverter SPLC-ESD up to 0.75 kW

The NIETZ ESD series frequency inverter offers the best price due to the minimization of functions for solving the simplest control tasks of a low-power three-phase motor 220V.

Before purchasing a scalar frequency inverter

In our store, there is a wide range of scalar frequency inverters for motors. Choose a model and purchase it with delivery to any city in Ukraine. To choose an inverter, you need to determine its main characteristics, such as the manufacturer, series, number of phases, etc. You can do this yourself using the filters on the site or seek help from our specialists.

We offer you to consider our new series SPLC-US , which is an analogue of SPLC-ESD-0R7G1. Main differences: lighter case, reduced weight due to a smaller cooling radiator, cheaper price.
