Motor (output) choke 90A, 380V, 37 kW, 0.078 mH (OCL-0090-078U-0.4SC)
In Stock
Product Code:
SPLC-OCL-0090-078U-0.4SC
Brand:
Specialist
13 093,50 UAH
Qty:
Do you have any questions about the product?
We will be happy to answer them in messengers
Delivery of goods
More details
New Post Office and address
≈ 250 UAH / Free for orders over 5,000 UAH
2-4 days
By courier in Ukraine
≈ 350 UAH / Free for orders over 5,000 UAH
1-2 days
Pickup from our warehouse
Free
Today, after 2:00 PM
Payment
More details
Technical specifications
Description
Three-phase motor choke 90A, 380V, 37 kW, 0.078 mH OCL-0090-078U-0.4SC is installed at the output of a frequency converter to filter current supplied to three-phase electric motors of 380V. The purpose of the output reactor is as follows:
- Creating inductive resistance that limits the motor supply current, thus preventing overload and damage;
- Preventing sudden current spikes during motor startup, which can damage equipment;
- Cleansing the current sine wave from unwanted high harmonics (high-frequency noise) occurring in the electric drive.
Use the AC output choke in the circuit between the frequency converter and asynchronous motor to improve power supply quality to the drive, and ensure safe and long-term equipment operation.
Technical characteristics of the motor output choke OCL-0090-078U-0.4SC
| Operating Voltage | 3 phases 380 V |
|---|---|
| Voltage Drop | 1% for 380 V (less than 4%) |
| Operational Frequency | 50/60 Hz |
| Operating Current | 90 A |
| Maximum Current | may exceed operating current by no more than 150% for 60 s |
| Inductance | 0.078 mH |
| Insulation Class | F, H |
| Protection Class | IP00 - IP22 |
| Noise | ≤65 dB |
| Temperature Rise | ≤85 K |
| Dielectric Strength | AC 3000 V/50 Hz/5 mA/10 s |
| Insulation Resistance | 100 VDC, ≤100 MΩ |
| Operating Ambient Temperature | -25 ~ +45℃ |
Operating Conditions of Motor Choke (Line Reactor) OCL-0090-078U-0.4SC
- Within the temperature range from minus 10 to 45℃ the nominal parameters of the choke are as specified in the table. At temperatures above 55℃, the nominal current decreases by approximately 2% for each additional +1℃.
- The altitude should not exceed 2000 m above sea level.
- Air humidity less than 90%.
- Environment: no harmful gases, flammable items, presence of good ventilation.
When placing the choke in a cabinet, ensure ventilation to provide adequate cooling of the equipment.
