Motor (output) choke 660A, 380V, 280 kW, 0.011 mH (OCL-0660-011U-0.4SA)
In Stock
Product Code:
SPLC-OCL-0660-011U-0.4SA
Brand:
Specialist
54 353,28 UAH
Qty:
Do you have any questions about the product?
We will be happy to answer them in messengers
Delivery of goods
More details
New Post Office and address
≈ 250 UAH / Free for orders over 5,000 UAH
2-4 days
By courier in Ukraine
≈ 350 UAH / Free for orders over 5,000 UAH
1-2 days
Pickup from our warehouse
Free
Today, after 2:00 PM
Payment
More details
Technical specifications
Description
Three-phase Motor Choke 660A, 380V, 280 kW, 0.011 mH OCL-0660-011U-0.4SA is installed at the output of a frequency converter to filter the current supplied to three-phase 380V electric motors. The purpose of the output electric choke is as follows:
- Creating inductive resistance, which limits the motor supply current, thereby preventing its overload and damage;
- Preventing sharp current surges during the motor start-up that could damage the equipment;
- Cleansing the current sine wave from unwanted high harmonics (high-frequency noise) that occur in the drive.
Use the AC output choke in the circuit between the inverter and the asynchronous electric motor to improve the power supply quality of the drive, as well as to ensure safe and long-term equipment operation.
Technical Specifications of the Motor Output Choke OCL-0660-011U-0.4SA
| Operating Voltage | 3 phases 380 V |
|---|---|
| Voltage Drop | 1% for 380 V (less than 4%) |
| Operating Frequency | 50/60 Hz |
| Operating Current | 660 A |
| Maximum Current | may exceed operating by no more than 150% for 60 s |
| Inductance | 0.011 mH |
| Insulation Class | F, H |
| Protection Class | IP00 - IP22 |
| Noise | ≤65 dB |
| Temperature Rise | ≤85 k |
| Dielectric Strength | AC 3000 V/50 Hz/5 mA/10 s |
| Insulation Resistance | 100 VDC, ≤100 MΩ |
| Ambient Operating Temperature | -25 ~ +45℃ |
Operational Conditions of the Motor Choke (Line Reactor) OCL-0660-011U-0.4SA
- Within the temperature range from minus 10 to 45℃, the nominal parameters of the choke are tabular. At temperatures above 55℃, the nominal current decreases by approximately 2% with each additional +1℃.
- Altitude should not exceed 2000 m above sea level.
- Humidity should be less than 90%.
- Environment: without harmful gases, flammable objects, and with good ventilation.
When placing the choke in a cabinet, ensure ventilation for sufficient equipment cooling.
