Air preparation unit for a 1 ½″ compressor for 3.5 m³/min cleaning 0.01 micron

SCC-WS-FJ30-40-G-C-T-A is an air preparation system for a compressor up to 3.5 m³/min for high-pressure boosting up to 16 bar. The compressed air unit has a connection thread size for inlet-outlet of 1 ½ inches, and for maximum efficiency, it is advisable to install it immediately after the refrigerant cooler, and in its absence — after the compressor receiver. The moisture-oil separating filters clean compressed air to a degree of 0.01 μm. Filtration is carried out in four stages — initially a cyclone separator, followed by a coarse filter 3 μm to a fine filter up to 0.01 μm. This construction principle allows:

• Less frequent system shutdowns for maintenance (filter replacements)
• Reduced cost on the most expensive fine-filter cartridges
• Effective removal of all types of impurities: moisture, dust and solid particles, as well as residual compressor oil
• Higher energy efficiency — minimized pressure losses, differential manometer shows the pressure drop and signals the need for replacement of clogged filter elements

The cost of professional assembly of air purification filters for a compressor up to 3500 L/min includes fittings, taps, differential manometer and installed cartridges at 3 μm, 1 μm and 0.01 μm.

Compressed Air Cleaning System for Compressor 0.01 μm

The compressed air filtration and cleaning set consists of 4 devices:

• SCC-WS30-40 — cyclone type moisture separator for compressor 1 ½″. This air and water separator operates without consumables — it removes most of the droplet moisture carried by the compressed air flow. With the dryer, the filter cartridges become less soiled. Includes a manual tap for draining condensate. For maximum efficiency, it should be installed not immediately after the compressor but after the refrigerant dryer of compressed air, such as SCC-MPWF-20.
• SCC-FJ30-40(C) moisture-separating filter for compressor 1 ½″ with replaceable filter element “C” at 3 μm, with condensate discharge tap.
• SCC-FJ30-40(T) is a similar air filter 1 ½″, as the previous one, but with a filter element “T” at 1 μm.
• SCC-FJ30-40(A) with thread 1 ½″, with filter element “A” at 0.01 μm, tap and differential manometer.

At Specialist you can buy air preparation for a compressor 0.01 μm in one block.
