Screw compressors 11 kW SCC-ZAI-15 with receiver and dryer

Specialist SCC-ZAI-15 series screw compressor is a ready-made assembly of an oil-filled screw compressor with a 11 kW motor connected to the industrial power grid at 380 Volts. Produces 1200~1700 l/min of dry air per minute at 8 bar. The compressed air is dried by a dryer and moisture separators installed on top of a 300 l tank to save space.

The SCC-ZAI-15 screw compressor assembly performs several functions:

• air supply with adjustable outlet pressure from 7 to 10 bar. On request, models with an outlet pressure of up to 12 bar are supplied;
• cooling and effective moisture removal from air contained in the atmosphere;
• air storage in the tank and pressure pulsation smoothing in the pneumatic system.

The compressor is controlled via a controller with a touch screen. Using a Wi-Fi connection, you can view compressor parameters and get notifications about filter replacements on your mobile device or computer. The enclosure has a protection rating of IP23.

Performance of the SCC-ZAI-15 Series Screw Compressors and Model Selection

When choosing a model, consider that the capacity of any compressor depends on the set outlet air pressure. Use the table to purchase a SCC-ZAI-15 screw compressor of the required power.

The pressure value of 1.2 MPa (12 bar) is indicated for custom-order compressor models that support an outlet pressure of up to 12 bar.

Design and Advantages of the SCC-ZAI-15 Single-Stage Screw Compressor

The "4 in 1" compressor assembly consists of the following main elements:

1. compressor
2. refrigerant air dryer
3. group of separator-moisture separators
4. tank

The compressor unit consists of the following elements:

• screw block (pair)
• electric motor with direct drive
• air-oil separator
• oil pipeline system
• cooling system
• air duct system
• electric control system (controller and built-in electrical cabinet)

Compared to peers on the Ukrainian market, Specialist industrial screw compressors are assembled from quality and durable components. We have filters and spare parts for after-warranty service in stock.
