Solenoid valve carbon dioxide remote control 2.2 mm for semi-automatic welding machines, SV-WZ-ES-22NC-2.2-A

Do you have any questions about the product?
We will be happy to answer them in messengers

Solenoid valve carbon dioxide remote control 2.2 mm for semi-automatic welding machines, SV-WZ-ES-22NC-2.2-A

Name: Solenoid valve carbon dioxide remote control 2.2 mm for semi-automatic welding machines, SV-WZ-ES-22NC-2.2-A
Brand: Specialist
SKU: SV-WZ-ES-22NC-2.2-A-DC24V
Price: 577.98 UAH
Availability: InStock

In Stock

Приєднання

8/6 мм

Diameter of conditional passage

2.2

Power Voltage

AC220V DC12V DC24V

Model

Manufacturer

Specialist

from 577,98 UAH

Qty:

Do you have any questions about the product?
We will be happy to answer them in messengers

Delivery of goods

More details

New Post Office and address

≈ 250 UAH / Free for orders over 5,000 UAH

2-4 days

By courier in Ukraine

≈ 350 UAH / Free for orders over 5,000 UAH

1-2 days

Pickup from our warehouse

Free

Today, after 2:00 PM

Payment

More details

Models

Found 3 variants


Name

Model Price Availability Qty

Action

SV-WZ-ES-22NC-2.2-A-DC24V

Solenoid valve carbon dioxide remote control 2.2 mm for semi-automatic welding machines, SV-WZ-ES-22NC-2.2-A

Diameter of conditional passage=2.2 Power Voltage=DC24V Приєднання=8/6 мм

SV-WZ-ES-22NC-2.2-A-DC24V

577,98 UAH

In Stock

SV-WZ-ES-22NC-2.2-A-DC12V

Solenoid valve carbon dioxide remote control 2.2 mm for semi-automatic welding machines, SV-WZ-ES-22NC-2.2-A

Diameter of conditional passage=2.2 Power Voltage=DC12V Приєднання=8/6 мм

SV-WZ-ES-22NC-2.2-A-DC12V

577,98 UAH

In Stock

SV-WZ-ES-22NC-2.2-A-AC220V

Solenoid valve carbon dioxide remote control 2.2 mm for semi-automatic welding machines, SV-WZ-ES-22NC-2.2-A

Diameter of conditional passage=2.2 Power Voltage=AC220V Приєднання=8/6 мм

SV-WZ-ES-22NC-2.2-A-AC220V

577,98 UAH

In Stock

Technical specifications

Приєднання

8/6 мм

Connection type

Tree

Coil voltage

AC220V, DC12V, DC24V

Nominal diameter

TWO 2.2

Nominal diameter

2.2

Тип контролю

Electromagnetic

Description

Electromagnetic valve for semi-automatic SV-WZ-ES-22NC-2.2-A (type A) for use with chemically neutral gases and liquids, can be used in various installations (for instance, air-plasma cutting), but are most commonly purchased as solenoid gas cut-off valves for semi-automatic and automatic welding machines, connected to pipelines via a "tree" Ø8 mm at the inlet and Ø6 mm at the outlet.

The feature of welding valves SV-WZ-ES-22NC-2.2-A is a reliable brass body, its high corrosion resistance, and the valve's capability to withstand high temperatures (up to 90°C) and pressure (up to 8 bar) of the working medium. The nominal bore diameter is 2.2 mm, ensuring an optimal flow of protective gas for welding. The gas valve is a two-way two-position normally closed valve (2/2 NC) and will not allow gas to pass to the torch without voltage on the solenoid coil. The valve starts gas flow from inlet to outlet on signal and remains open until power is cut off.

Welding Valve Parameters 2/2 NC SV-WZ-ES-22NC-2.2-A
Design		Two-way two-position normally closed valve with unilateral electro-control
Materials		Brass, NBR (VITON)
Connection		8 mm inlet, 6 mm outlet
Operating Temperature Range		-5~80 °C (with dry air without moisture)
Power Supply Voltage		DC12V, DC24V, AC220V 50/60 Hz
Working Medium		Neutral gases and liquids
Operating Pressure	Air	up to 6 bar
Max. Pressure	Air	8 bar
