Industrial full-function controller SPLC-XL3-16R XL3 series (processor module)

SPLC-XL3-16R is the main processor unit of the modular industrial economy controllers of the XL3 series manufactured by Xinje, featuring 16 built-in I/O points and supporting expansion up to 352 points using expansion modules.

• The controller is programmed in the free XDPPro environment using ladder diagrams, instruction lists, and function blocks;
• 8 built-in discrete inputs and 8 relay outputs, to which the required number of analogue or discrete I/O can be added by installing the appropriate modules;
• It is possible to install 1 compact ED module on the left and up to 10 expansion modules on the right, which can increase the number of input-output points, communication ports, or specialised ones. If you use more than 5 modules, you also need to equip the controller with the SPLC-XL-ETR terminal resistor. Some modules also require the installation of remote terminal blocks;
• special functions — pulse output, high-speed counter, pulse width modulation, frequency measurement, dual-axis control, etc.
• built-in ports that support communication protocols Modbus, RS232, and RS485, can also be expanded
• real-time clock, data retention function in case of power failure, and interrupt processing.
